Simucube 2 Sport

SKU: Simucube 2 Sport Motor
$1,099.00

Details

Details

SIMCUBE 2 SPORT - Direct Drive

The Simucube 2 Sport Direct Drive System raises the bar for sim racing steering wheel systems. It offers the most realistic and detailed force feedback currently available through a high torque, brushless motor. Designed for sim racing enthusiasts, the Sport 2 offers a serious amount of power with up to 17Nm of direct drive torque. Highly responsive and accurate, it provides a highly detailed driving experience.

  • The ultra low latency will give you incredible feel, you can feel and then correct those small slides sooner, putting you a step ahead of your opponents
  • A precision machined quick release system will give you a rock solid feel and a guided rail design that makes a steering wheel change very easy to do
  • A high efficiency direct drive motor and clever electronics with heat guiding means the system produces less heat and doesn't require a noisy fan to keep it cool
  • Built in wireless receiver that will automatically connect to a wireless steering wheel and has an unbreakable millisecond range response time
  • 2 years manufacturers warranty

Not only can the Sport wheel base produce a huge amount of torque, it is also highly accurate with robotics grade angle sensors and high quality encoders. This combined with custom made electronics and all wrapped up inside a full metal CNC machined case means that the Sport is a solid unit that is capable of providing the very best in sim racing force feedback. The wheel base system works with the Simucube quick release wheel side kit which is available to purchase separately. The wheel side kit simply clips onto the wheel base and it locks in place with a safety pin. This system allows you to have multiple steering wheels where you can quickly change wheels with ease.

COMPARE MODELS

SIMUCUBE 2 SPORTSIMUCUBE 2 PROSIMUCUBE 2 ULTIMATE
MOTORDirect Drive optimized ultra low torque ripple motorHigh response speed Direct Drive optimized ultra low torque ripple motorMaximum response speed, low inertia, Direct Drive optimized ultra low torque ripple motor
SIMUCUBE WIRELESS WHEEL™ SUPPORTIncludedIncludedIncluded
SIMUCUBE QUICK RELEASE™Not IncludedNot IncludedIncluded
MAX TORQUE *17 Nm25 Nm32 Nm
MAX TORQUE SLEW RATE4.8 Nm/ms8.0 Nm/ms9.5 Nm/ms
ANGLE SENSOR22 bit absolute22 bit absolute24 bit Hiperface
TORQUE OFF BUTTONStandard (Premium optional)Standard (Premium optional)Premium (with remote power switch)
POWER SUPPLY280 WR1 2 x 280 W / R2 1 x 450 W Peak1000 W
WHEEL BASE DIMENSIONS INCL. SQR™130 x 130 x 250 mm130 x 130 x 270 mm115 x 115 x 310 mm
MOUNTING HOLESM8 x 4 pcs threaded holeM8 x 4 pcs threaded hole9 mm dia x 4 pcs through hole
MOUNTING HOLE PATTERN DIA145 mm145 mm130 mm
FLANGE CENTERING HOLE DIA110 mm110 mm110 mm
WHEEL BASE WEIGHT8.0 kg11.1 kg11.3 kg
STANDARD WARRANTY24 months24 months60 months
*) Torque is continuous until motor gets very hot. In preliminary testing, no-one has managed to cause torque to start throttling.
SIMUCUBE 2 SPORTSIMUCUBE 2 PROSIMUCUBE 2 ULTIMATE
TORQUE RECONSTRUCTION PROCESSINGYesYesYes
STATIC FORCE REDUCTIONYesYesYes, in detail adjustable
NATURAL DAMPING, INERTIA AND FRICTION FILTERSYesYesYes, in detail adjustable
ULTRA LOW LATENCY MODEYesYesYes
TORQUE SLEW RATE ADJUSTMENT1 – 4.8 Nm/ms1 – 8.0 Nm/ms1 – 9.5 Nm/ms
